Pollak 7 Way Blade Trailer Plug Wiring Diagram. Here is the diagram for 7-pin connector. 7 Way Plug Wiring Diagram Standard Wiring Post Purpose Wire Color TM Park Light Green Battery Feed Black RT Right TurnBrake Light Brown LT Left TurnBrake Light Red S Trailer Electric Brakes Blue GD Ground White A Accessory Yellow This is the most common Standard wiring scheme for RV Plugs and the one used by major auto manufacturers today.
GREEN 7 - W a y W i r e c o l o r Wire color gauge White 10 gauge Blue 12 gauge Green 14 gauge. Get it as soon as Thu Jan 14. Pollak 7 Pin Trailer Connector Wiring Diagram Wiring Library Trailer Connector Wiring Diagram 7-Way.
POLLAK 12-706 Plastic Blade Style 7-Way Plug.
7-Way round plug lets you connect your trailer to the 7-way round blade connector of a tow vehicle Interlock system locks in place to keep connections secure Over-sized finger tabs. Heavy duty 6-way 4-way terminals accept up to 12 gauge wire. Interlock system keeps connections in place. Article by Scott Bostic.
